Specification | Span width | Bay spacing | Eave height | Ridge height | Main frame profile |
(m) | (m) | (m) | (m) | (mm) |
SLP-3 | 3 | 3 | 2.5 | 3 | 48*84*3 |
SLP-6 | 6 | 3 | 2.5 | 3.5 | 48*84*3 |
SLP-8 | 8 | 3 | 2.5 | 3.9 | 48*84*3 |
SLP-10 | 10 | 3 | 2.5 | 4.3 | 48*84*3 |
SLP-15 | 15 | 5 | 4 | 6.43 | 108*150*3 |
SLP-18 | 18 | 5 | 4 | 6.9 | 112*203*4.5 |
SLP-20 | 20 | 5 | 4 | 7.2 | 112*203*4.5 |
SLP-25 | 25 | 5 | 4 | 8 | 112*203*4.5 |
SLP-30 | 30 | 5 | 4 | 8.8 | 112*259*5.5 |
SLP-40 | 40 | 5 | 5 | 11.8 | 120*310*6.0 |
Details:
Optional Size:
1)Span Width: 3m,6m,8m,9m,10m,12m,15m,18m,20m,21m,25m,30m,40m.
2)Length: not limited,extended by 3m and 5m.
3)Eave height: from 2m to 10m,standard is 2.5m and 4m.
Frame Material:
1)High-strength aluminium alloy with Fluorine carbon paint
coating(PVDF).
2)Conector is made of zinc powder-coated steel.
3)The frame is strong,durable,light in weight,not easy to rust and
distort.
Cover Material:
1)Double PVC-coated polyester textile.Any color is available.
2)Waterproof, flame retardant to DIN4102 B1, M2, UV resistant.
3)850g/m2 for roof PVC, Corrugated steel for wall
4)The maximum allowed wind speed is 100km/h.
Application:
Outdoor Events: These tents are widely used for outdoor events such as weddings,
parties, concerts, festivals, trade shows, exhibitions, and
corporate gatherings. Their spacious interiors can accommodate
large crowds and provide protection from the elements.
Sporting Events: Heavy-duty aluminum structure tents are often used to create
temporary stadiums, spectator seating areas, VIP lounges, and
hospitality suites for sporting events like marathons, races,
tournaments, and championships.
Hospitality and Catering: Hotels, resorts, restaurants, and catering companies utilize
these tents to expand their event spaces, host outdoor dining
experiences, set up bars, lounges, and create special event venues.
Industrial and Commercial Use: These tents are employed for industrial purposes such as
warehousing, storage, manufacturing, and logistics. They provide
temporary or semi-permanent solutions for sheltering equipment,
materials, products, and machinery.
Emergency and Relief: In emergency situations or disaster relief efforts, heavy-duty
aluminum structure tents serve as temporary shelters, medical
facilities, command centers, and distribution points. They offer a
quick and efficient way to provide essential services and support
to affected communities.
Construction Sites: Construction companies use these tents as temporary offices,
storage areas, workshops, and break rooms on construction sites.
They provide a safe and weather-resistant environment for workers
and equipment.
