Tent installation steps :

Step 7: Erect the gable wall
All teams will be divided into four, two men pulling the rope, two men at the corner joints, the rest at the apex,
Lift the gable up, after lifting to a certain height, the middle personnel respectively ran to both sides to help the gable continue to lift up
Up. The man who pulls the wire rope will also pull the gable upward with the force. When the whole gable reaches 70 degrees
Stop for a moment and then slowly erect perpendicular to the ground, while the person pulling the wire rope stands on one side with a little force to hold the top steady
Live. At the same time, several people need to hold the post. Install the flat iron end of the cross rod under the upper end of the column by two personnel
That screw on top and tighten the nut. Connecting the other end of the cross bar to the bottom plate of the adjacent second gable
At the bottom hole, insert the screw and tighten the nut. It should be noted that the bottom plate must be fixed in advance, otherwise pull
The floor moves when the gable is raised. Use the same method to erect the second gable and install the other two crossing poles.
As shown in the following picture: the two gables after the installation of the cross pole can be completely loosened, with the cross pole, the tent frame
It forms a lot of triangles. So it's pretty stable. The next job is to install beams and purlins.
Step 8: Install beams and purlins
The cross section shape of the beam is in the shape of the house, and the cross section shape of the purlin is square. Installation method is as follows, the beam or
Purlins are angled upwards and then angled to hang the purlins into U-lugs on the corner joints or diagonal beams
The pi-shaped iron. Use a ladder to slowly lift the straight hook end of the beam/purlin and hang it into the gable on the opposite side of the hook
The hanging ear of the beam or corner node. Under normal circumstances, there are three beams between the two gables, that is, one at each end, in
A purlin increases or decreases according to the size of the span. Hang all the beams and purlins in first gear,
Taking a span of 15 meters as an example, three beams and four purlins need to be hung. Then pull the wire cable to the Angle node
The first hole position, and tighten, tighten the wire rope when you must fix the wire rope at the top of the flower cable to prevent
Rotate the wire rope as you rotate the cable. Use the same method to erect the other gables and install the cross
Liang. In the middle of the gables, because there is no wire cable installed, it is necessary to tie the top node with twine to lift and stabilize the mountain
The role of walls. Beams and purlins must be installed immediately whenever a gable is erected.
Step 9: Install the support
Connect the center stay to the small hole in section A of the inclined beam, insert the screw, and tighten the nut. After installing the center brace, turn the side
The beam is hung into the Angle node and the hanging ear of the center support. Note that when hanging the side beam, be sure to install it from the side beam fitting end first
To install, first hang the end of the side beam fitting into the hanging ear in the Angle node, and then slowly lift the straight hook end to install it in the center
Support the upper hanging ear, remember not to install the straight hook end first, otherwise the installation will not be successful. As with beams and purlins,
You must first install from the bent hook end, and then hang the straight hook end.
Step 10: Install the roof
Thread the straps on both ends of the cloth top into the twine and pull the straps toward the inside of the tent. Then the cloth will tip the head of both
Insert the side tape into the slot of the diagonal beam, swing the other end of the rope across the entire frame of the tent, and then four people
Pull the rope so that the top of the cloth slowly pulls along the groove of the diagonal beam to the opposite side. Remember to use force at the same time, otherwise cloth the top
It will stick and cause it to not move. To solve this problem, just pull the top of the cloth back to a certain position and then re-use it at the same time
Lila, make sure you put the top on and move forward. Pull the other cloth tops in the same way.
Step 11: Install the side triangle
Similar to the installation of the cloth top is also needed to use rope, but when installing the side triangle, someone must stand (with
The pull rope next to the top node, the only difference is that the pull strap of the side triangle is on the outside. Put the side triangle first
Go into the slot of the skew beam, and then the person standing in the middle pulls up to the rope, while the person standing at the corner node needs to help hold it
The side triangle is raised so that the strip goes up the groove. When installing the side triangle, be sure to pay attention to the difference between left and right, do not
It's installed backwards. After pulling the two side triangles, cut the rubber strip from the lower end of the middle seam tube between the two side triangles
Place slowly up through (seam tube with flat iron one facing inside). Hang the flat iron into the top when it reaches the top joint
At the same time, insert the lower end where the rubber strip is cut off into the lower end of the middle seam pipe.
Step 12: Install the curtain
Open the curtain with the front (the side with the rope or the side with the cover) facing outwards and thread the tape through the post first
Where to mill the groove. Then slowly pull up to the top, insert the lifting code into the gap in the beam milling groove, pay attention
Plug in one by one, after plugging, the lower end of the curtain rubber strip is also plugged down from the milling groove of the column,
Then pull the curtain toward the center, and place the side with the rope behind the side with the canopy loop, and turn the rope from top to top
Next string together.
Step 13: Install the top pressure rod
Insert the cloth top press rod into the cloth top press rod sleeve (that is, there is a double layer sleeve at the top end of the cloth, and then press the end
The iron is placed inside the press rod and the rectangular screw is threaded into the seamless tube of the Angle node. Note: Two pieces of cloth top middle
Connect with a direct pressed iron. This step can also be performed in front of the curtain installation. The last step is to push the curtain down
(1 inch galvanized pipe) is inserted into the pressure rod sleeve at the bottom of the curtain to prevent the wind from blowing the curtain. Here, the whole installation
The process is over.
